Touchmonitor Specifications
Model ET1915L
LCD Display 19” TFT Active Matrix Panel
Display Size 376.32(H) x 301.06(V) mm
Pixel Pitch 0.294(H) x 0.294(V) mm
Display Mode VGA 640 x 350 (70Hz)
VGA 720 x 400 (70Hz)
VGA 640 x 480 (60 / 72/ 75Hz)
SVGA 800 x 600 (56 / 60 / 72/ 75Hz)
XGA 1024 x 768 (60 / 70 / 75Hz)
Max. Resolution SXGA 1280 x 1024 (60 / 70 / 75Hz)
SXGA (1280 x 1024) at 75Hz maximum
Contrast Ratio Typical: 800:1; Min: 500:1
Brightness IntelliTouch: typical 270cd/m 2 ; min. 204cd/m 2
AccuTouch: typical 240cd/m 2 ; min. 180cd/m 2
Non-Touch: typical 300cd/m 2 ; min. 240cd/m 2
Acoustic Pulse Recognition: typical 270cd/m 2 ; min. 204cd/m 2
Response Time (Rise+Fall) 5 ms typical; 10ms max.
Display Color 16.7M
Viewing Angle Vertical CR>10, 80 deg (Up) / 80 deg (Down) typical
70 deg (Up) / 70 deg (Down) min.
Horizontal CR>10, 80 deg (Left) / 80 deg (Right) typical
70 deg (Left) / 70 deg (Right) min.
Input Signal Video R.G.B. Analog 0.7Vp-p, 75 ohm
Sync TTL Positive or Negative
Signal Connector Mini D-Sub 15 pin
Front Control Menu, , , Select, Power
OSD Contrast, Brightness, H-Position, V-Position, Sharpness
Color Temperature, Phase, Clock, OSD Time, Recall,
Language: English, French, German, Spanish, Japanese
Plug & Play DDC1 / 2B
Touch Panel (optional) IntelliTouch, AccuTouch, APR
Power Adapter Input AC 100-240V, 50/60Hz
Operating Conditions Temperature 0
o
C ~ 40
o
C (32
o
F ~ 104
o
F)
Humidity 20% ~ 80% (No Condensation)
Altitude To 12,000 Feet
Storage Conditions Temperature -20
o
C ~ 60
o
C (-4
o
F ~ 140
o
F)
Humidity 10% ~ 90% (No Condensation)
Dimensions (HxWxD) 429 x 390 x 212mm
Weight (Net) 8.4Kg
Certifications UL, C-UL, FCC-B, CE, VCCI, C-Tick, MPRII , TUV,
EK, MIC
