REMARKS DESCRIPTION QTY PART NUMBER ITEM
STAND 1 30511057733 1
SCREW 5X22 2 90016205022 2
SCREW 5X20 1 90024405020 3
INCLUDES ITEM 5 TANK, FUEL 1 A350000660 4
SPACER 2 13104528230 5
WASHER 5 2 90060300005 6
SCREW 5X16 2 90016205016 7
VENT ASY 1 A356000030 8
CLIP 2 13201326630 9
REPOWER BULK OPTION: 90015 PIPE, VENT - 3X6X115mm 1 V471000110 10
REPOWER BULK OPTION: 90017 PIPE, RETURN - 3X6X80mm 1 13201256030 11
REPOWER BULK OPTION: 90015 PIPE, FUEL - 3X6X170mm 1 13201052030 12
GROMMET, FUEL 1 13211555930 13
FILTER, FUEL 1 1 13120519830 14
INCLUDES ITEM 16-17 CAP ASY 1 13100455530 15
GASKET, CAP 1 13101655830 16
CONNECTOR, CAP 1 13105156030 17
Footnotes
1: Also Included In REPOWER TUNE-UP KIT
99922204021 - 7 - REVISED 05/19/09
Table of Contents Part Number Index
SRM-230 Trimmer Fuel System
