Echo TRIMMER SRM-230 User Manual
Page 15

REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
WING BOLT
1
21041752730
1
LID, AIR CLEANER - GRAY
1
13031306563
2
LID, AIR CLEANER - BLACK
1
13031305863
3
FILTER, AIR
1
1
13031054130
4
PLATE, PREVENT
1
12901152730
5
SCREW 5X60
2
90024205060
6
CASE, AIR CLEANER - GRAY
1
P021000991
7
CASE, AIR CLEANER - BLACK
1
P021004480
8
See Carburetor Diagrams For Additional Information
CARBURETOR
1
------------------
9
GASKET, INTAKE
2
1
13001013410
10
INSULATOR
1
13001756431
11
SCREW 5X25
2
90016205025
12
GASKET, INTAKE
2
1
13001055930
13
Footnotes
1: Also Included In REPOWER TUNE-UP KIT
2: Also Included In GASKET KIT
99922204021
- 15 -
REVISED 05/19/09
SRM-230 Trimmer
Intake
