Echo TRIMMER SRM-230 - Manual (Page 23)

REMARKS DESCRIPTION QTY PART NUMBER ITEM
INCLUDES ITEMS 2-18 SHORT BLOCK 1 SB1061 1
SCREW 5X22 4 90016205022 2
CYLINDER 1 A130000341 3
GASKET, CYLINDER 1 1 V100000060 4
INCLUDES ITEMS 6-9 PISTON KIT 1 P021001102 5
RING, PISTON 2 A101000000 6
PIN, PISTON 1 10001311520 7
CIRCLIP, PISTON PIN 2 10001504630 8
SPACER, PISTON PIN 2 10001411520 9
INCLUDES ITEM 11 CRANKSHAFT ASY 1 A011000042 10
BEARING, NEEDLE 1 V553000010 11
INCLUDES ITEMS 13-18 CRANKCASE KIT 1 P021000941 12
OIL SEAL 1 10021305530 13
BEARING, BALL 6001 2 90080036001 14
CIRCLIP 28 1 90070200028 15
GASKET, CRANKCASE 1 1 10024255930 16
OIL SEAL 1 10021228230 17
SCREW 5X25 4 90016205025 18
Footnotes
1: Also Included In GASKET KIT
99922204021 - 23 - REVISED 05/19/09
Table of Contents Part Number Index
SRM-230 Trimmer Engine, Short Block -- SB1061
