6
Technical Specifications
Connection data at X101
Power supply Power over Ethernet according to IEEE 802.3af
Voltage POE 48 VDC (min. 44 V, max. 57 V)
Power consumption 3.5 W
Display 128 x 64 pixels
Ringing sound pressure level max. approx. 95 dB (A) at 1 m
Housing (height x width x depth) 293 x 191 x 128
Weight approx. 2,300 g
Operating position Table or vertical wall mounting
Receiver Microphone Electret-foil microphone
Receiver inset Dynamic receiver inset with magnetic field generator
Connection X101 (10/100 Mbit/s) LAN cable with 8 conductors
AWG 22 to 24 for solid conductors, or
AWG 24 for multi-wired conductors
Dimensions Connecting cable / Cable entry
Cable glands M20 x 1,5
Blind plugs M20 x 1,5 / M12 x 1,5
Connecting cable diameter 6 – 13 mm
Connection potential compensation 1,5 – 4 mm 2
Ambient temperature range and explosion protection
Type of protection II 3 G Ex nA nL IIC T5
II 3 D Ex tD A22 IP65 T80°C
Operating ambient temperature range -20°C
≤ Ta ≤ +55°C
Storage and transport temperature -25°C
≤ Ta ≤ +70°C
Housing degree of protection IP65
Labelling
Firma FHF Funke+Huster Fernsig GmbH
Type FernTel IP Z2
DEKRA BVS 08 ATEX E 022
CE 0158 II 3 G Ex nA nL IIC T5
II 3 D Ex tD A22 IP65 T80°C
-20°C
≤ Ta ≤ +55°C
IP65 Ui 60 VDC
IECEx Ex nA nL IIC T5
IECEx BVS 08.0009
