4
1
10
2
11
12
13
17
FIG. 1
FIG. 2
5. Attach the Tube-12(#12) to the Tube-17 (#17) using spring lock. See FIG.2.
6. Attach the Tube-13(#13) to the Tube-17 (#17) using spring lock. See FIG.2.
1. Find a clean, level place to begin the assembly of your Football Game. We recommend that two adults work
together to assembly this football game.
2. Remove all the parts from the box and verify that you have all of the listed parts as shown on the Parts List
below.Carefully cut or tear the four corners of the box so that the bottom of the box can be used as your work
surface
3. Attach the Tube-10(#10) to the Tube-1 (#1) using spring lock. See FIG.1.
4. Attach the Tube-11(#11) to the Tube-2 (#2) using spring lock. See FIG.1.
ASSEMBLY INSTRUCTIONS
Spring Lock
Spring Lock
Spring Lock
