CoUNTErS/TIMErS

Real-Time Timers/Counters: Four 32-bit
programmable
Watchdog Timers: Two, time-out generates
interrupt or reset

MISCELLANEoUS

Reset, Abort and JTAG/COP via on-board debug
connector
Two planar LEDs for Fail and CPU active

PowEr rEqUIrEMENTS

(AltiVec disabled)

+ 3.3V ± 5% @ 20° C

PrPMC8005E-12xx:

3.3 A typical, 3.9 A

maximum

PrPMC8005E-13xx:

4.1 A typical, 4.5 A

maximum

VIO:

PCI buffer diode clamping

voltage

DEMoNSTrATED MTBF

(based on a sample of eight boards in accelerated
stress environment.)

Mean: 190,509 hours
95% Confidence: 107,681 hours

SAFETy

All printed wiring boards (PWBs) are manufactured
with a flammability rating of 94V-0 by UL recognized
manufacturers.

ENVIroNMENTAL

Operating

Non-operating

Temperature:

0° C to +55° C,
forced air
cooling

Humidity (NC): 5% to 85%

5% to 95%

Vibration:

1.0 G sine
sweep, 5.0
to 100 Hz, 25
octaves/min

0.5 G sine sweep;
50-500 Hz; 0.1
octaves/min 3.0 G
sine sweep; 5-50 Hz;
0.25 octaves/min

ELECTroMAgNETIC CoMPATIBILITy (EMC)

Intended for use in systems meeting the following
regulations:

U.S.: FCC Part 15, Subpart B, Class A (non-residen-
tial)
Canada: ICES-003, Class A (non-residential)

This product was tested in a representative system
to the following standards:

CE Mark per European EMC Directive 89/336/EEC
with Amendments; Emissions: EN55022 Class B;
Immunity: EN50082-1
