Page 15: Rotary disconnect switches – fusible, Dimensions in inches (mm)
14
For more information visit us at: www.eatonelectrical.ca
December 2004
Technical Data and Specifications F-Frame
Dimensions in Inches (mm)
Figure 10. Fusible F-Frames
Table 12. Dimensions in Inches (mm)
ᕃ
C363UF800L when used with optional terminal lugs CUS1000LN.
ᕄ
C363UF600J when used with optional terminal lugs CUS600LN.
C363UF600J
C363UF800L
ቢ
ባ
ш 1.30
ш (33.0)
3.42
(86.9)
2.36 (59.9)
2.36 (59.9)
J
4.17
(105.9)
H3
C
H2
9.17
(232.9)
9.53
(242.1)
ቢ
ባ
H
H1
Y
5.98
(151.9)
J1
9.52
(241.8)
4.72
(119.9)
12.67
(321.8)
K1
K
A
X
Y
ቢ
ባ
B
Dual Dimensions
Inches (mm)
Description
A
B
C
H
H1
H2
H3
J
J1
K
K1
Y
3-Pole
ᕃᕄ
17.18
(436.4)
14.25
(362.0)
12.87
(326.9)
9.74
(247.4)
11.06
(280.9)
8.66
(220.0)
7.75
(196.9)
13.58
(345.0)
1.51
(38.4)
9.84
(250.0)
4.92
(125.0)
7.48
(190.0)
Rotary Disconnect Switches – Fusible
