Mini-MT User Guide
Revision 1.02
GSM2228UG001 Page 2
2 Product Specifications
System Requirements Application Interface
Interface: USB
L x W x H:
100.33 x 58.92 x 25.4 mm
Housing: Polycarbonate
Weight:
136 g
TX Power: Class 4
(2W @850/ 900 MHz)
Class 1
(1W @1800/1900 MHz)
Special Features
- Motion Sensor
- Vibrating Alert
• Host Protocols: AT Commands, UDP/API,
CMUX
• Internal Protocols: PPP, UDP/API,
UDP/PAD, CMUX, TCP/PAD
• API Control/Status: AT
• Real-Time-Clock (RTC), Event Engine
Scriptable, Friends IP, Wake-Up and Keep
Alive, Auto-Activate
• Over the air commands for:
- GPS TX Interval - GPS Content
- Binary Reporting - Event Reporting
- Timed Reporting - Distance Reporting
- Geo-Fencing
Band Operation SIM Card / Interface / I/O
850 / 900 / 1800 / 1900 MHz bands
• Internal 3V SIM accessed via battery
compartment
• Mini USB jack for power and programming
• Vehicle power adapter (optional)
• 2.5 mm headset jack
GPRS Packet Data Environment
Mode: Class B, Multislot 10 Certified
Protocol: GPRS Release 97, SMG 31
Coding Schemes: CS1 – CS4
Packet Channel: PBCCH/PCCCH
Operating: -20°C to +60°C
Storage:
-40°C to +85°C
Humidity: Up to 95% non-condensing
GSM Functionality GPS/A-GPS Functionality
Voice: Full Rate, Enhanced full rate and
half rate, AMR
CS Data: Asynchronous, transparent and
non transparent up to 9.6 KB
GSM SMS: PDU, MO/MT Cell broadcast
• Autonomous and “Enhanced” Autonomous
• GPS operations w/ optional Multi-day
ephemeris service
• Tracking up to 14 satellites
• 3GPP A-GPS standards compliant
• Supported Protocols
-
Secure User Plane Location (SUPL)
- NMEA
• Time to First Fix (Cold Start):
-
70 sec @ 10 m avg.
• 1 Hz Navigation Fixes
Certifications Power
FCC: Parts 2,15,22, & 24
GCF: Version 3.21.1
PTCRB: Version 3.7.1
CE Mark
Industry Canada (CSA0
RoHS Compliant
Rechargeable Lithium Ion Battery:
Standard
1340mAh
GSM hibernate 100μA
GSM 1TX/1RX (Avg) 150mA
GSM1RX (Avg) 75mA
Part Number
- PN – GSM2228
