12432-9-0107 Page 19
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
Index Part
No. Number Description
Index Part
No. Number Description
33 712098 Gasket for Observation
Hole Cover
34 DV-781 Lighting Hole Cover w/Mica
35 DV-064 Cover Plate for Observation Hole
36 DV-691 Seal Bracket
37 712059 Gasket Tubing Seal
38 DV-847 Burner Door Natural Gas
38 DV-972 Burner Door LP Gas
39 DV-779 Gasket for Burner Door
40 722040 Manifold Union
41 R-2147 Gas Valve VR8204C 1126 LP Gas
(10.0")
41 R-2149 Gas Valve VR8204C 1001
Natural Gas (3.5")
42 UH-810 Transformer Mounting Bracket
43 R-1995 Transformer
44 UH-451 Junction Box Cover
45 11760 Outer Casing Bottom (USA)
45 15690 Outer Casing Bottom (Canada)
46 8720148 Bushing
47 872053 Cord Set
48 DV-571 Control Compartment Divider
49 DV-671 Manifold Support
50 DV-765 Gasket for Chamber Air Inlet
(Top & Bottom) (Two Required)
51 DV-764 Gasket for Chamber Air Inlet
(Sides) (Two Required)
52 DV-692 Control Module Mounting Bracket
53 872050 Wire Harness for Control Module
54 R-1616 Control Module
55 8720140 Bushing
56 DV-614 Left Inner Shield
57 11759 Side Panel
Not Shown R-1196-D Fan and Limit Wire
Not Shown R-6389 24 Volt Wall Thermostat
Not Shown 862060 Lighter Rod
Not Shown 742245 Pilot Orifice LP
Not Shown 7421110 Pilot Orifice Natural
1 11762 Outer Casing Top
2 632024 Motor Mount (Four Required)
3 11764 Motor Mounting Bar (Two Required)
4 712059 Gasket (Two Required)
5 R-619 Motor
6 11787 Fan Blade
7 11766 Fan Housing
8 DV-559 Upper Front Panel
9 11759 Side Panel
10 DV-613 Right Inner Shield
11 DV-725 Vent Cap
12 DV-131 Outside Mounting Plate
13 DV-548 Air Inlet Tube
14 DV-524 Flue Outlet Tube
15 DV-600 Vent Kit Complete
(Nos. 11, 12, 13, 14)
16 DV-567 Air Drop Welded Assembly
17 712036 Gasket for Flue Outlet Flange
18 DV-579-C Combustion Chamber
19 8720130 Bushing
20 11765 Switch Compartment Assembly
21 912073 Limit Control
22 R-1941 Fan Control
23 DV-832 Switch Compartment Cover
24 DV-562 Lower Front Panel (USA)
24 15667 Lower Front Panel (Canada)
25 DV-826 Rear Burner
26 732062 Spark Plug Wire
27 762217 Pilot with Orifice LP Gas
27 762113 Pilot with Orifice Natural Gas
28 DV-808 Pilot Tubing
29 DV-824 Front Burner
30 P-88-42 Main Burner Orifice Natural Gas
(Two Required)
30 742223 Main Burner Orifice LP Gas
(Two Required)
31 DV-687 Manifold and Plate Assembly
32 712045 Manifold Gasket
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your
equipment. Then determine the Part Number ( not the Index Number) and the Description of each part from the following appropriate
illustration and list. Be sure to give all this information . . .
Furnace Model Number
Part Description
Furnace Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, IL 62222-0529
HOW TO ORDER REPAIR PARTS
PARTS LIST
