54 LSHB 150 A1
GB
Appliance description
Rotary switch LUX
2 Rotary switch TIME
3 Rotary switch SENS
4 Motion Detector
5 Bracket
6 Protective screen
7 Screw
8 Bulb
9 Cable entry
10 Locking screw
Assembly / Electrical connection
Selecting the installation location
The appliance can be mounted indoors or in a covered outdoor area.
DANGER
► Maintain a suffi cient distance from the illuminated area (at least 1 m),
otherwise there is a risk of fi re from the generated heat.
The motion detector 4 may be oriented at about 170° horizontally and about
180° vertically and has a detection range of max. 120°.
The range is adjustable from about 5 - 12 m.
When selecting the installation location ensure there will be no adverse incidents
registered in the coverage range, such as from roads or lights.
