Before installation / Preparing for use
Before installation
Important: The electrical connection must be
carried out by a qualified electrician or someone
trained to perform electrical installations. This person
must be familiar with the properties of the light and
all connection regulations.
Familiarise yourself with all instructions and
diagrams in this manual as well as with the
light before installation.
Before installation, ensure that the cable that
the light is to be attached to is not live. To do
this, remove the fuse or switch off the circuit
breaker in the fuse box (0 position).
Use the voltage tester to check that there is
no voltage.
Preparing for use
Mounting the light
Note: you will need a drill for installation.
CAUTION! RISK OF INJURY! Refer to your
drill’s operating instructions.
Remove the end cap 3a by pressing it lightly
out of the fastening and moving it away to the
side. The end cap, beneath which is the terminal
block
6 needed for connection, is marked
(see label “Output wire”).
Remove the cover 1 by moving it away to the
side.
Remove both bulbs 2 . Remove the respective
light bulb 2 by turning it a ¼ turn and pulling
it out of the socket. Use a clean, lint-free cloth
when you are replacing a bulb.
To uncover the mounting openings 7 , remove
the chromed reflector inside the ceiling lamp.
To do so, rotate the two white plastic caps ¼
turn to the left and pull them out.
Then remove the reflector.
Hold the light on the required position on the
ceiling.
Mark the drill holes for the installation openings 7
(see fig. B).
Drill the holes (ø approx. 6 mm, depth approx.
40 mm). Make sure that no electrical wiring is
damaged during this operation.
Insert the dowels in the drilled holes. Use a
hammer if necessary.
Insert the supplied screws into the dowels and
let them project a distance of about 2.0 mm
from the ceiling or mounting surface.
Insert the screws into the mounting openings
provided for them 7 of the light and align
the light by pushing it to the left or to the right.
Finally tighten the screws.
Now re-insert the chromed reflector and fasten
it with the previously removed plastic caps by
inserting them into the openings provided for
them and rotating them ¼ turn to the right.
Check for correct fitting.
Route the mains connection cable (external)
5
through the opening provided for it 4 in the
end cap that was previously removed 3a .
Note: Carefully remove the pre-punched
connection plate from the opening
4 for the
mains connection cable (external) 5 so you
can guide the cable through the opening 4 .
Now connect the connection cable of the light
to the mains connection cable (external) 5 by
means of the terminal block 6 provided.
Note: Ensure that each wire of the mains
connection cable (external) is properly con-
nected in the correct place: live wire, black or
brown = symbol L, neutral wire, blue = symbol N,
protective earth wire, green-yellow = symbol .
Insert the two bulbs 2 once again. Insert each
bulb 2 into the socket and tighten it with a
¼ turn. Check for correct fitting.
Reinsert the cover 1 and put the end cap 3a
back on the light housing. Ensure that the end
cap is correctly seated.
Your light is now ready for operation.
Replacing a bulb
CAUTION! RISK OF ELECTRIC SHOCK!
To replace the bulb , first of all disconnect the light
from the mains circuit. To do this, remove the fuse
