4 GB/IE

LED solar spotlight

Intended use

This product is suitable for outdoor use. This prod-
uct is not intended for commercial use.

Not suitable for ordinary lighting in
household room illumination.

Description of Parts

1

Low voltage socket

2

Mounting hole for main station

3

Main station

4

AUTO / OFF switch

5

Locking screw (motion detector)

6

Motion detector

7

Spotlight

8

Rotary control LUX (light sensitivity)

9

Rotary control SENS (sensitivity)

10

Rotary control TIME (switched on duration)

11

Solar electricity socket

12

Screw (ø 4.5 x 40 mm)

13

Solar cell

14

Screw (ø 3.7 x 28 mm)

15

Solar cable plug

16

Mounting holes for solar cell

17

Wall bracket

18

Dowel (ø 8 mm)

19

Signal LED

20

Lead gel rechargeable battery

21

Dowel (ø 6 mm)

Included items

Immediately after unpacking, check that all the
items and accessories are present and that the
device is in perfect condition.

1 Main station (consists of spotlight with 80 LEDs,

motion detector, battery housing with built-in
rechargeable battery)

1 Solar cell (incl. approx. 4.75 m power cable)

2 Screws (mounting material for main station,

ø 4.5 x 40 mm)

4 Screws (mounting material for solar cell,

ø 3.7 x 28 mm)

2 Dowel (mounting material for main station,

ø 8 mm)

4 Dowel (mounting material for solar cell, ø 6 mm)
1 Operating instructions

Technical data

Operating voltage:

12 V

Lead gel rechargeable
battery:

6 V

, 4 Ah, dimensions:

10 x 7 x 4.5 cm

Lamp:

80 LEDs, 0.06 W

Solar cell:

150 x 200 mm,
amorphous, 2 Wp,
max. 10 V , 140 mA

Connection for
charging device:

12 V

, min. 400 mA,

polarity

, DC con-

nector 5.5 x 2.1 mm
(charging device not
included with delivery.)

Dimming switch:

Adjustable from approx.
10 lx–20,000 l x

Motion detector:
Range:

Max. 12 m

Detection angle:

approx. 180° horizontal,
50 ° vertical

Protection type:

IPX4 (splash-proof)

Safety notes

DANGER TO

LIFE AND ACCIDENT HAZARD
FOR TODDLERS AND SMALL

CHILDREN! Never leave children unsupervised
with the packaging materials. The packaging
material presents a danger of suffocation.
Children often underestimate dangers. Always
keep children away from the product.
