Detaching the Worktop
After the worktop has been removed the appliance can be installed
underneath a continuous worktop.
The procedure is as follows:
☞
1. Unscrew the Philips screws (F) on the
right and the left.
2. Lift the worktop slightly, push it about
20 mm towards the rear, and lift it off
upwards (G).
Unscrew the holding bracket (H) and
keep it in a safe place.
Installation
8
If your refrigerator is installed under
a continuous worktop, an air outlet
opening of at least 200 cm
2 and a
ventilation grille (A/B) matching the
worktop design should be installed at
the rear of the worktop.
The cut surfaces of the worktop (C)
should be varnished to avoid swelling
due to penetration of moisture.
The appliance wall distance must be
at least 30 mm and should be
checked before the ventilation grille is inserted.
Special accessories:
A Ventilation grille, brown
B Ventilation grille, white
G 56/1
G
H
F
AEG36
A/B
200 cm
2 105
C
570
550
93-103
