13 GB/IE/CY
Installation
Note: You will need a crosshead
screwdriver to fit the attachment
clips
3 and screws 4 , 8 .
Note: The product is suitable for
mounting on walls or cupboards.
Note:
Use the flat surface for easy
insert. The stick 1 can be turned
inside the clip for angle adjustment.
Cupboard mounting
(Fig. A–D):
Install the attachment clips in the
desired position with the screws
4 (see Fig. A).
Attach the light strip to the
attachment clips (see Fig. B).
Wall mounting
(Fig. E–H):
Drill the fastening holes in the wall.
CAUTION! Ensure that you do
not damage any cables in the wall.
Insert the dowels 7 into the
drilled holes (see Fig. E).
Fix the attachment clips 3 to
the wall with the screws 8 (see
Fig. E).
Attach the light strip 1 to the
attachment clips (see Fig. F + G).
