40 GB
Safety / Preparation / Preparation for use
bags, Styrofoam etc. can turn into dangerous
toys for children.
J Use only halogen bulbs with lamp
covers or in low-voltage systems.
J Only use the included parts, using other parts
will void the warranty.
J Do not look directly into the light source (light
bulb, LED etc.).
For your safety
J Use only 12 volt halogen bulbs type G4 with
a maximum rated power of 20 watts.
J Fit the light in such a way to ensure it is
protected from damp and dirt.
J Make careful preparations for the assembly
and take sufficient time. Clearly lay out all
components and any additional tools or materials
that might be required so that they are readily
to hand.
J Remain alert at all times and always watch
what you are doing. Always proceed with
caution and do not assemble the lamp if you
cannot concentrate or feel unwell.
J Never touch halogen bulbs with your bare
hands, otherwise damage to the bulbs may
occur. If you find you have touched a bulb with
your bare hands, wipe the halogen bulb clean
using alcohol and a fluff-free cloth.
Q
Preparation
Q Required tools and materials
The tools and materials mentioned are not included
in the delivery. The details and values given are
non-binding and for guidance only. The nature of
the material depends on the individual circumstanc-
es on site.
- Pencil / Marking tool
- Screwdriver
- Electric drill
- Drill
- Spirit level
- Cable detector
- Measuring tape
Q Preparation for use
Q
Installing the light
Note: The product includes two different types of
screw. Use the countersunk head screws (length:
15 mm) for mounting on to wood. Use the counter-
sunk head screws (length: 25 mm) and the dowels
1 for mounting on to a solid masonry wall.
1. Measure up the wall or mounting surface
before drilling the holes. Use a spirit level to
improve accuracy.
2. Mark the two mounting holes at a distance of
570 mm apart.
Steps 3 and 4 apply only to mounting on
to solid masonry:
3. Now drill the fixing holes (approx. ø 5 mm,
depth approx. 30 mm). Make sure that you do
not damage any electrical cables during this
operation.
4. Insert the supplied dowels 1 into the drilled
holes.
5. Fix the under-unit light 2 in place with the
screws 3 (see Fig. A).
6. Place the caps 4 on the screw heads.
7. Insert the connector plug of the mains lead 5
into the light connector socket 6 .
8. Insert the mains plug of the mains lead 5 into
the mains socket.
Your light is now ready for operation.
Q Connecting more than one
under-unit light together
CAUTION! First ensure that all the under-unit lights
are connected by connection cable
14 before you
insert the mains plug of the mains lead 5 into
