Opti RGB / Opti RGB WH

©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040

www.ElationLighting.com • Toll Free (866) 245-6726

DMX TRAITS

Channel Value

Function

1

0 - 255

Red ( 0% 100% )

2

0 - 255

Green ( 0% 100% )

3

0 - 255

Blue ( 0% 100% )

4

16 - 255

Color macra

5

0 - 15

No function

16 - 255

Strobe/speed control

6

0 - 31

No function

Dimming Control

32 - 63

Dim Bright

64 - 95

Bright Dim

96 - 127

Dim Bright Dim

128 - 159

Color mixing

160 - 191

3 color change

192 - 223

7 color chcange

224 - 255

Sound active

7

0 - 255

Dimming ( 0% 100% )

Product Order Code

Description

OPTI RGB

Black OPTI RGB

OPTI RGB WH

White OPTI RGB

Accessories Order Code

Description

PRO CLAMP

Mounting Clamp

DF 64

Diffusion filter

OPTI RGB 45D KIT

45° Lens Kit

OPTI/BDB

Barn door
