8
1.) Status Display.
2.) Directory (Album) Number.
3.) Track Number Display.
4.) PROG (Program) Indicator – Appears when programming tracks or
playing programmed tracks.
5.) DIR (Directory) Indicator.
6.) SHUFF (Shuffle) Indicator – Appears when Random playback mode
is selected.
7.) INTRO Indicator – Appears when Intro playback mode is selected.
8.) MP3 Indicator – Appears when playing CD’s containing mp3 audio
files.
9.) CD Indicator – Appears when playing normal CD discs.
10.) HOLD Indicator – Appears when HOLD switch is set to ‘On’ position.
11.) Repeat 1/ALL Indicators – Appears when the Repeat playback mode
is selected.
12.) Battery Status Indicator.
13.) Elapsed Time (Seconds) Display.
14.) ESP Indicator – Indicates Anti-Skip Protection is activated.
15.) Elapsed Time (Minutes) Display.
LCD DISPLAY INDICATORS
1
2
3
4 5 6 7 8 9 10 11 12
13
14
15
