Chapter 5: Product Specifications Efficient Networks
®
5800 Series
User Reference Guide
Page 5-2 Efficient Networks
®
Table 5-1: Front Panel Light Indications
Light Color Indications
PWR Green
Off
Power is ON
Power is OFF
TEST Yellow:
Green: (2 sec blink)
Off: Running Power On Self Test
Self Test successful
Router is shut down
LINK Yellow:
Green:
Off: Establishing DSL modem link
DSL modem link successful
DSL modem link is shut down
WAN Green flashing:
Off:
WAN transmissions detected
No WAN transmissions detected
LANT Green flashing:
Off:
Transmitting LAN traffic
Not transmitting LAN traffic
LANR Green flashing:
Off: Receiving LAN traffic
Not receiving LAN traffic
