Extender D
VGA Line Driver with Audio for Decora ® -style Wall Plate
unique feAtures
• Mounts in an included Decora ® -style wall plate
• Decora trim plate included
moDeL version DesCriPtion PArt #
Extender D Decora mount, White - 3" (8 cm) pigtails .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-759-22
Extender Wall Mount Series
l i n e D r i v e r s
Extender WM
VGA Line Driver with Audio for One-Gang Electrical Wall Box
unique feAtures
• Wall-mountable in a one-gang box and fits flush into a wall, podium, or table
moDeL version DesCriPtion PArt #
Extender WM Black - 3" (8 cm) pigtails .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-398-12
Extender WM White - 3" (8 cm) pigtails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-398-22
Extender AAP
VGA Line Driver with Audio - AAP Version
unique feAtures
• Installs in products that accept a double space AAP - Architectural Adapter Plate
moDeL
version DesCriPtion PArt #
Extender AAP Black - 3" (8 cm) pigtails .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70-147-12
Extender AAP White - 3" (8 cm) pigtails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70-147-22
Extender AAP EX Black - 18" (46 cm) extended pigtails .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70-147-72
