Replacing the ink roller
1. Turn the power switch off.
2. Remove the printer cover. (Figure 1)
3. Lift the ink roll out from the roll holder. (Figure 2)
4. Install a new ink roll into position. (Figure 3)
5. Replace the printer cover. (Figure 4)
Installing printing paper
1. Lift up the paper arm. (Figure 5)
2. Place the new paper roll on the arm. The edge of the paper
should be positioned as shown. (Figure 6)
3. Insert the paper into the slit at the back of the machine as
indicated. (Figure 7)
4. Turn the power switch on. Press the paper feed key to advan-
ce the paper as shown.(Figure 8)
