8
1.) OPEN Switch – Slide to the right to unlock and open the CD
door.
2.) Battery Compartment (on bottom cabinet).
3.) SKIP REV. Button.
4.) P. MODE Button – Selects the playback mode: Repeat 1/All, Shuffle,
or Intro.
5.) PROG. (Program) Button.
6.) DC 4.5V Input Jack – Connect an AC adapter (not included) to this
jack to use 120V 60Hz house current.
7.) CD Door.
8.) PLAY/PAUSE Button.
9.) Multifunction LCD Display.
10.) CD-AM-FM Selector Switch.
11.) HOLD ’On/Off’ Selector Switch.
12.) STOP Button.
13.) TUNING Control.
14.) SKIP FWD. Button.
15.) VOLUME Control – Raises or lowers the volume.
16.) Headphone Jack – Connect stereo headphones, included, to this
jack.
17.) BBS ‘On/Off’ Switch - Slide to the right to increase bass response.
