VSC 100
Video Scan Converter
User’s Manual
1-3
Nominal level ............................... RGBHV/RGBS ........................ 0.7V p-p
S-video, composite video ...... 1.0V p-p
Impedance .................................... 75 ohms
Sync
Input type ..................................... Autodetect RGBHV, RGBS, RGsB
Output type .................................. RGBHV, RGBS
Standards ...................................... NTSC 3.58 and PAL
Input level ..................................... 1.5V to 5.0V p-p
Output level .................................. 5.0V p-p
Input impedance .......................... 75 ohms
Output impedance ....................... 75 ohms
Polarity .......................................... Negative
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 15 watts,
internal, auto-switchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 1
0% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount ................................... No
Enclosure type .............................. Metal
Enclosure dimensions ................. 2.25" H x 9.00" W x 6.25" D
5.72 cm H x 22.86 cm W x 15.88 cm D
(Add 0.5” for front panel knobs and 0.75” for
rear panel connectors.)
Shipping weight ........................... 6 lbs (2.7 kg)
Vibration ....................................... ISTA 1A in carton
(International Safe Transit Association)
Approvals ..................................... UL, CUL, CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor
Specifications are subject to change without notice.
Included Parts:
Mac – VGA cable (m-m) _ 26-462-01 (6' )
S-video cable _ 26-316-02 (6' )
Power cord _ 27-044-01 (USA and Canada)
