2.8 TIRES 20 HP & 23 HP Kohler Units
Drive Front Caster
Rear Caster
(Single Tail Wheel)
Pneumatic (Air-Filled) Semi-Pneumatic Semi-Pneumatic
Quantity 2 2 1
Tread Turfmate Smooth Smooth
Size
23 x 10.50-10 9 x 3.50-4 13 x 6.5-6
Ply Rating 4
Pressure 13 psi (90 kPa)
27 HP Kohler Units
Drive Front Caster
Rear Casters
(Dual Tail Wheel)
Pneumatic (Air-Filled) Semi-Pneumatic Semi-Pneumatic
Quantity 2 2 2
Tread AT101 Smooth Smooth
Size
24 x 12.00-12 9 x 3.50-4 13 x 6.5-6
Ply Rating 4
Pressure 9 psi (62 kPa)
2.9 MOWER DECK (Sold Separately)
2.9.1 Models FR524 FR604
Discharge Side Discharge Side Discharge
Cutting Width 52 in. (132 cm) 60 in. (152 cm)
2.10 DIMENSIONS
2.10.1 Overall Width: w/52” Deck w/60” Deck
without deck 49.0 in. (124.5 cm) 49.0 in. (124 cm)
deflector up 53.3 in. (135.4 cm) 61.4 in. (156 cm)
deflector down 64.0 in. (163 cm) 72.0 in. (183 cm)
2.10.2 Overall Length: 20 & 23 HP Kohler 27 HP Kohler
without deck & floor pan folded 80.4 in. (204.2 cm) 82.3 in. (209.0 cm)
w/52” Deck 112.4 in. (285.5 cm) 114.3 in. (290.3 cm)
w/60” Deck 112.4 in. (285.5 cm) 114.3 in. (290.3 cm)
2.10.3 Overall Height: Roll Bar - Up Roll Bar - Down
69.2 in. (175.8 cm) 50.7 in. (128.8 cm)
2.10.4 Curb Weight: without Deck 911 lbs. (413 kg)
w/52” Deck 1303 lbs. (591 kg)
w/60” Deck 1348 lbs. (611 kg)
2.10.5 Tread Width (Center to Center of Drive Wheels):
For 27 HP Kohler Units: 41.4 in. (105.2 cm)
For 20 HP & 23 HP Kohler Units: 38.9 in. (98.8 cm)
2.10.6 Wheel Base (Center of Drive Wheel to Center of Rear Caster Wheel):
For 27 HP Kohler Units: 51.2 in. (130.0 cm)
For 20 HP & 23 HP Kohler Units: 54.1 in (137.4 cm)
2.10.7 Minimum Turning Radius:
For 27 HP Kohler Units: 55.25”
For 20 HP & 23 HP Kohler Units: 56.3”
