Functional description
After connecting the suction and pressure
hoses and filling the garden pump with wa-
ter, it will output a defined volume of clear
water.
Technical Data
Garden pump ..........FGPS 1100 B2
Mains connection ............230 V~, 50 Hz
Power consumption ............... 1100 Watt
Suction lift ...................................... 7 m
Max. discharge rate ..............4.600 l/h*
Max. discharge head .................... 45 m
Max. water temperature ................ 35 °C
Hose connection ............................... 1“
Safety class ......................................... I
Degree of protection ........................IPX4
Noise pressure
level (L
pA
) ...75,2 dB (A); K
pA
= 3,0 dB (A)
Noise performance level
(measured) / (L
WA
)
...........88,24 dB (A ); K
WA
= 2,89 dB (A)
Noise performance level
(guaranteed) ............................ 91 dB (A)
* With the included suction hoss (14),
the maximum discharge rate of the gar-
den pump can not be reached.
Commercial use will invalidate the guar-
antee.
The operator or user is responsible for ac-
cidents or damage to other people or their
property.
The manufacturer shall not be liable for dam-
ages caused by use other than for which the
equipment is intended or by incorrect opera-
tion.
General Description
Scope of Delivery
- Garden pump
- Carrying handle
- 2 Srews
- Pressure hose
- Seal ring
- Adapter
- Prefilter with reflow stopper
- Instruction Manual
The diagram of the most impor-
tant functional elements can be
found on the foldout side.
Overview
1 Protective cap A
2 Water inlet
3 Protective cap
4 Water outlet
5 On/Off switch (not visual)
6 Power cable
7 Carrying handle
8 2 Screws
9 Filler screw
10 Draining screw
11 Adapter
12 Seal ring
13 Connector water inlet
14 Pressure hose
15 Prefilter with reflow stopper
16 Connector Prefilter
