SCP 226 Series
SCP 226
Secondary Control Panel for MLC 226 IP and System 5 IP
unique Features
• Three-gang faceplate
SCP 226 AAP
Secondary Control Panel with AAP Opening for
MLC 226 IP AAP and System 5 IP
unique Features
• Five-gang faceplate
• Opening for up to four single space AAP - Architectural Adapter Plates;
AAPs sold separately
SCP 226 L
Secondary Control Panel with Lectern Faceplate for
MLC 226 IP L and System 5 IP
unique Features
• Low profile, 3.2" (8.1 cm) tall faceplate fits into a compact space on a lectern
or desk
• Mounts in a rack or wall using an Extron UCM RAAP or UCM 10X8P Universal
Controller Mounting Kit; mounts on a desk using an Extron SMB 203 L Lectern
Series Mount Box
SCP 226
Secondary Control Panel for MLC 226 IP and System 5 IP
- No Faceplate
unique Features
• No faceplate for custom installations
• For use with any of the MLM 226 Series mounting options
M e d i a L i n k ™ c o n t r o L L e r a c c e s s o r i e s
ModeL
Version desCriPtion Part #
SCP 226 Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-02
SCP 226 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-03
SCP 226 RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-05
ModeL
Version desCriPtion Part #
SCP 226 AAP Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-12
SCP 226 AAP White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-13
SCP 226 AAP RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-15
ModeL
Version desCriPtion Part #
SCP 226 L Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-32
SCP 226 L White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-33
SCP 226 L RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-35
ModeL
Version desCriPtion Part #
SCP 226 Controller Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-671-00
400
