Electro-Voice Speaker - Manual (Page 7)

Xds Double Subwoofer System
Xds Double Subwoofer System
7
Figure 5 — Distortion
Distortion for the Xds was measured on axis
in the far field in an anechoic environment
with an input signal that would result in a
sound pressure level of 115 dB at one meter.
The Klark Teknik DN8000 digital electronic
unit was used to provide the necessary cross-
over filters, equalization and time delay. The
sound pressure level was normalized for an
equivalent one-meter distance. Plots of sec-
ond and third harmonic distortion are shown
referenced to the fundamental.
Figure 6 — Impedance
The impedance of each frequency band of
the Xds was measured in an anechoic envi-
ronment
Figure 7 — Wiring Diagram
The wiring diagram of each frequency band
of the Xds is shown.
+
_
+
_
BLACK SPEAKER TERMINAL IS "-"
8 OHMS NOMINAL
5.0 OHMS DC
SUB2:
SUB1:
PINS 3 & 4 PARALLELED
PINS 2 PARALLELED
PINS 1 PARALLELED
RED SPEAKER TERMINAL IS "+"
BLACK
4+
4 -
3+
3 -
2+
2 -
1+
1 -
3 -
3+
4 -
4+
BLACK
BLUE
BLACK
RED
WHITE
BLACK
RED
BLACK
RED
BLACK
BLUE
BLACK
WHITE
SUB2
5.0 OHMS DC
8 OHMS NOMINAL
SUB1
BLACK
RED
RED
2 -
1+
1 -
BLACK
RED
BLACK P
A
RA
LL
EL
ED CO
NNECT
O
RS
2+
