Features & Specifications
(1) Features
n Comply with IEEE 802.3 10Base-T, 10Base-2 and 10Base-5 Ethernet Standards.
n Support sixteen RJ-45 connectors for 10Base-T connection and two auto-detect
10Base-2 BNC/10Base-5 AUI ports for mixed media network environment.
n Built-in uplink port for easy connection to another hub using regular straight-
through cable.
n Complete sets of LEDs provide an easy diagnostic on the hub’s and individual
port’s status.
n Standard 19" rackmount
n Two-year warranty
(2) Specification
n Standards : IEEE 802.3
n 10Mbps Ports : RJ-45 x 16 & AUI /BNC x 2
n Hub LEDs : Power, Collision, Jabber
n Port LEDs : RJ-45 - Link/Receive, Partition
n Dimensions : 17.4 x 5.55 x 1.75 inches/442 x 141 x 44 mm
n Weight : 4.04 lb./1.833kg
n Power : external full-range, 110-240V AC, 50-60Hz
n Operating Temperature : 32-131
0 F (0-55 0 C)
n Operating Humidity : 10-95% (Noncondensing)
n Emission : FCC Class A & CE Mark
