SW6 VGA Audio • Introduction
Introduction
SW6 VGA Audio Switcher
1-2
About the SW6 VGA Audio Switcher
The SW6 VGA Audio (SW6 VGA A) (figure 1) is a 6-input,
1-output audio/video switcher housed in a rack mountable,
1U high, full width metal enclosure with internal, universal,
100-240 VAC, 50/60 Hz power supply.
Sound System
Extron
SW6 VGA Audio
Switcher
AUDIO
INPUTS
PC
PC PC
PC
Mac
Mac
Projector
Figure 1 — Typical SW6 VGA Audio application
2
Chapter Two
Installation and Operation
Mounting.the.Unit
Connections
Operation
