SW6 VGA Audio • Reference Information

Reference Information, cont’d

SW6 VGA Audio • Reference Information

A-4

A-5

Control/remote — switcher

Serial control port ......................... RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations . 2 = TX, 3 = RX, 5 = GND
Contact closure .............................. 9-pin female D connector
Program control ............................. Extron’s control/configuration program

for Windows

®

Extron’s Simple Instruction Set (SIS

)

General

Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 30 watts,

internal

Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

Cooling ........................................... Convection, unvented
Rack mount .................................... Yes, with optional 9.5" deep rack shelf,

part #60-190-01 (RSU 129) or 60-604-01
(RSB 129)
Furniture mountable with optional
under-desk mounting kit, part #70-219-01
(MBU 129)

Enclosure type .............................. Metal
Enclosure dimensions .................. 1.75" H x 17.1" W x 9.4" D

(1U high, full rack wide)
4.4 cm H x 43.4 cm W x 23.9 cm D
(Depth excludes connectors.)

Product weight .............................. 4.5 lbs (2.0 kg)
Shipping weight ........................... 7 lbs (4 kg)
Vibration ........................................ ISTA 1A in carton

(International Safe Transit Association)

Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor

N

All nominal levels are at ±10%.

N

Specifications are subject to change without notice.

Part Numbers

Included parts

These items are included in each order for an SW6 VGA Audio:

Included parts

Part number

SW6 VGA Audio switcher

60-260-01

IEC power cord

Tweeker (small screwdriver)
SW6 VGA Audio User’s Guide
Captive screw 5-pole connectors

(qty. 7)

10-457-12

Extron Software Products CD

(Universal Switcher Control Program)

Cables

Male-to-male VGA cables

Part number

VGA M-M MD/3, 3' (0.9 m)

26-238-14

VGA M-M MD/6, 6' (1.8m)

26-238-01

VGA M-M MD/10, 10' (3.0m)

26-238-07

VGA M-M MD/25, 25' (7.6 m)

26-238-03

VGA M-M MD/50, 50' (15.2m)

26-238-18

Accessories

Accessory

Part number

RSU 129 1U Universal rack shelf

60-190-01

RSB 129 1U Basic rack shelf

60-604-01

MBU 129 Under-desk mounting bracket

70-219-01

Mac HV/VGA adapter

26-340-02

SY-VGA/XGA

26-173-01

KP 6 remote control keypad

60-111-20

IR 102 remote control kit

70-224-01
