LOCATION OF CONTROLS AND INDICATORS
TOP VIEW
1.) CD/Cassette Door PULL OPEN Tab.
2.) CD Door.
3.) Carrying Handle.
4.) FM Telescopic Antenna.
5.) Cassette Door.
6.) Cassette Control Keys.
(RECORD /PLAY Y /REWIND /F. FWD D /STOP OP /PAUSE
7.) VOLUME Button.
8.) VOLUME Button.
9.) CD PLAY/PAUSE Button.
10.) CD FWD. SKIP /TUNING Button.
11.) CD REV. SKIP /TUNING Button.
12.) CD STOP /BAND Button.
13.) FUNCTION Button.
14.) Preset EQ Button.
PLAY R E C O R D R E W I N D F. FWD P A U S E STOP
E Q F U N C T I O N S T O P / B A N D R EV. S K IP / TU N ING F W D.
PULL OPEN
V O L U M E
P L A Y / P A U S E
1
2
3
4
6
7
8
9 11 12 14 13
5
10
