Electro-Voice PL Series User Manual

Page 16

PL24/24S

PL44

PL80a

PL80c

PL84/84S

PL33

PL35

PL37

Element Type:

Dynamic,
Neodymium Mag-
net Structure

Dynamic,
Neodymium
Magnet Struc-
ture

Dynamic,
Neodymium
Magnet Structure

Self-Biased
Condenser

Dynamic,
Neodymium
Magnet Structure

Self-Biased
Condenser

Freq Response:

80 Hz - 16,000
Hz

80Hz -
18,000Hz

80Hz - 16,000Hz

50Hz - 20,000Hz

20 Hz - 10,000 Hz

50 Hz - 16,000 Hz

50 Hz -16,000 Hz

Polar Pattern:

Supercardioid

Cardioid

Supercardioid

Cardioid

Sensitivity, Open
Circuit Voltage,
1 kHz:

2.2 mV/Pa (-53 dBV)

3.5mV/Pa
(-49dBV)

0.50mV
(-66dBV).

2.2 mV/Pa (-53
dBV)

7.0mV (-43dBV)

Polarity:

Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3

Rated Impedance:

600 ohms

200 ohms

150 ohms

600 ohms

200 ohms

Connector:

3-pin, XLR-type

Finish:

Textured satin;
black

Textured satin, “PL
Classic” beige

Textured satin;
black

Dimensions:

(L) 7.20”
(183 mm)
(W) 2.10”
(53 mm)
Shank = 0.95”
(23.5 mm)

(L) 7.25”
(184 mm)
(W) 2.0”
(50.5 mm)
Shank = .93”
(23.5 mm)

(L) 7.48”
(190 mm)
(W) 2.0”
(51 mm)
Shank = 1.01”
(26 mm)

(L) 7.2”
(182 mm)
(W) 1.9”
(49 mm)
Shank = .94”
(24 mm)

(L) 5.6”
(142 mm)
(W) 2.32”
(59 mm)
Shank = 1.0”
(25.5 mm)

(L) 4.3”
(109 mm)
(W) 1.69”
(43 mm)
Height = 3.0”
(76 mm)

(L) 6.5”
(165 mm)
(W) 1.14”
(29 mm)
Shank = .85 “
(21.6 mm)

Accessories
Included:

Stand adapter
with Euro-thread
adapter, Soft zip-
pered gig bag

Stand adapter
with Euro-thread
adapter, Soft
zippered gig bag

Stand adapter
with Euro-thread
adapter, Soft zip-
pered gig bag

Locking stand
adapter with
Euro-thread
adapter, Soft
zippered gig bag

Locking stand
adapter with
Euro-thread
adapter, Drum rim
clamp DRC-1,
Soft zippered
gig bag

Locking stand
adapter with
Euro-thread
adapter, Soft zip-
pered gig bag

Net Weight:

10.4 oz (294 g)

10 oz (282 g)

11.8oz (333g)

9.3oz (261g)

12.9 oz (364 g)

8.3 oz (236 g)

6.3 oz (176 g)

Shipping Weight:

19.3 oz (547 g)

18.9 oz (536 g)

20.7 oz (587 g)

18.2 oz (516 g)

23.7 oz (672 g)

18.6 oz (527 g)

17.1 oz (485 g)

Max SPL

(1% THD @ 1 kHz):

—

141 dB SPL

—

132 dB SPL

Self Noise:

—

26dB SPL, A-
weighted

—

25 dB SPL, A-
weighted

Dynamic Range:

—

115dB

—

107 dB

Signal-to-Noise
Ratio:

—

68dB (@ 94dB
SPL)

—

69 dB (@ 94 dB
SPL)

Power Require-
ments:

None

Phantom: 11 to
52 VDC, 1.9mA

None

Phantom: 11 to
52 VDC, 4 mA
