Design LED 108IP
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free (866) 245-6726
COLORS
• 36 x 3W K2 LEDs - (12 each R, G, B)
• Long Life L.E.D. (rated at 100,000 Hours)
• Linear RGB color mixing allows for infinite color possibilities
PHOTOMETRICS
OUTDOOR RATED
IP
65
Design LED 108IP
Photometric Beam Angle Data
Standard 15° Lens: 44° Beam Angle
LUX x 0.0929 = FC
44°
Beam Angle
0 m
0 ft
1 m
3.28 ft
3 m
9.84 ft
2 m
6.56 ft
Ø 2.4 m Ø 7.9 ft
Beam Diameter
Ø 0.8 m Ø 2.6 ft Ø 1.6 m Ø 5.2 ft
Ø1.6m / Ø 5.2ft
Ø 2.4m / Ø 7.9ft
Ø 0.8m / Ø 2.6ft
R (12)
G (12)
B(12)
RGB (36)
440 FC / 4,729 LUX
664 FC / 7,152 LUX
41 FC / 443 LUX
1,199 FC / 12,900 LUX
118 FC / 1,272 LUX
180 FC / 1,940 LUX
12 FC / 127 LUX
342 FC / 3,680 LUX
53 FC / 570 LUX
77 FC / 831 LUX
5 FC / 55 LUX
136 FC / 1,465 LUX
47°
Beam Angle
0 m
0 ft
1.5 m
4.9 ft
3 m
9.84 ft
Ø 2.80 m Ø 9.2 ft
Beam Diameter
Ø 1.40 m Ø 4.6 ft
Ø 2.80 m / Ø 9.2 ft
Ø 1.40 m / Ø 4.6 ft
RGB (36) 64 FC / 690 LUX 16 FC / 168 LUX
Optional 25° lens: 47° Beam Angle (not included)
LUX x 0.0929 = FC
56°
Beam Angle
0 m
0 ft
1.5 m
4.9 ft
3 m
9.84 ft
Ø 3.20 m Ø 10.50 ft
Beam Diameter
Ø 1.60 m Ø 5.24 ft
Ø 3.20 m / Ø 10.50 ft
Ø 1.60 m / Ø 5.24 ft
RGB (36) 52 FC / 549 LUX 14 FC / 146 LUX
Optional 45° lens: 56° Beam Angle (not included)
LUX x 0.0929 = FC
