POWXQ5330 EN
Copyright © 2013 VARO P a g e | 9 www.varo.com
9.7 Adjustment of the saw blade and the base
 Position a try square against the saw blade and the sawing table.
 If the saw blade is not completely in line, then you can adjust the angle by means of the
screw.
 After this, you can adapt the zero position on the graduated scale.
9.8 Switching ON / OFF
For your safety use both hands to switch the power tool on and off.
 Connect the power tool to the power supply.
 Pull the on/off switch (14) in the direction of the handle. The saw blade rotates as long as
you keep the switch engaged.
 When you want to turn off the machine, you have to release the on/off switch (14).
9.9 Use of the laser
Your machine is provided with a laser function.
It helps you to saw through your workpiece at the right location.
 Insert the cable in the socket.
 Turn on the laser switch.
 Loosen the 2 screws and remove the guard cap.
 Loosen the other 2 screws and then moved the laser module back and forth, until it is
aligned with the saw blade.
 Retighten all screws and reinstall the guard cap.
