POWXG6010
EN
Copyright © 2010 VARO P a g e | 9 www.varo.com
Make sure the motor stopped and blade has come to a complete stillstand!!
 Lift the side flap and remove the side discharge channel.
 The side flap is automatically closed by a spring.
7 OPERATING INSTRUCTIONS
7.1 Before starting
Service the engine with EU95 or 98 and oil as instructed in the separate engine manual
packed in your mower. Read instructions carefully.
WARNING: never fill fuel tank indoors, with engine running or until the
engine has been allowed to cool for at least two minutes after running.
7.2 To start engine and engage blade
Fig 7A fig 7B
1. Attach spark plug wire to spark plug. If unit is equipped with a rubber boot over the end of
the spark plug, make certain the metal loop on the end of the spark plug wire (inside the
rubber boot) is fastened securely over the metal tip on the spark plug.
2. When starting cool engine, turn throttle choke lever to
“ ”position. When starting
warm engine, turn throttle choke lever to “ ”position. (Fig. 7A)
3. Standing behind the unit, operate the brake control handle and hold it against the upper
handle as shown in fig. 7B.
4. Grasp the recoil starter handle as shown Fig. 7B and pull up rapidly. Return it slowly to the
rope guide bolt after engine starts. Release the brake control handle to stop the engine and
blade.
7.3 Operation procedures
During operation, tightly hold the brake handle with both hands.
WARNING: During operation, when the brake handle is released, the engine
will stop and thus stopping the lawnmower from operating.
