Powerplus POWX242 TILE CUTTER 1100W 240MM EN - Manual (Page 10)

POWX242
EN
Copyright © 2014 VARO p a g e | 10 www.varo.com
11 CLEANING AND MAINTENANCE
Attention !Before performing any work on the equipment, pull the power
plug.
11.1 Cleaning
 Keep the ventilation slots of the machine clean to prevent overheating of the engine.
 Regularly clean the machine housing with a soft cloth, preferably after each use.
 Keep the ventilation slots free from dust and dirt.
 If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These
solvents may damage the plastic parts.
12 TECHNICAL DATA
Type POWX242
Mains voltage 230 V
Mains frequency 50 Hz
Power input 1100 W
No load speed 3000 min-1
Blade size (diameter x bore x thickness) Ø 250 x 25,4 x 2,2mm
Max. cutting depth (90°) 60 mm
Max. cutting depth (45°) 48 mm
Mitre angle 0-45°
Bevel 0-45°
Table dimensions 760 x 510mm
Max cutting length 600mm
Weight 52 kg
13 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
90 dB(A)
Acoustic power level LwA 110 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration) 2,4 m/s² K = 1,5 m/s²
14 SERVICE DEPARTMENT
 Damaged switches must be replaced by our after-sales service department.
 If the connecting cable (or mains plug) is damaged, it must be replaced by a particular
connecting cable which is available from our service department. Replacement of the
connecting cable must only be carried out by our service department (see last page) or by
a qualified person (qualified electrician).
