POWX204
EN
Copyright © 2014 VARO P a g e | 11 www.varo.com
11 TECHNICAL DATA
Voltage / frequency 230-240V ~50Hz
Power input 1500W
No load speed 9000 min
-1
Cuts / min : 18000
blade size : 210 x 16,5 x 1,5mm (2pcs)
jointer table size : 740 x 213mm
planer table size : 270 x 204mm
Dimensions of parallel guide 530x105 mm
Incline of parallel guide: from 0° to 45°
feeding speed : 6m/min
max planing width : 204mm
planing height / depth : 5 - 120mm
Max planing depth :
jointer : 0-3mm
planer : 0-2mm
net weight : 26.5 kg
12 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
93 dB(A)
Acoustic power level LwA 106 dB(A)
ATTENTION! Wear hearing protection when sound pressure is
over 85 dB(A).
13 SERVICE DEPARTMENT
 Damaged switches must be replaced by our after-sales service department.
 If the connecting cable (or mains plug) is damaged, it must be replaced by a particular
connecting cable which is available from our service department. Replacement of the
connecting cable must only be carried out by our service department (see last page) or by
a qualified person (qualified electrician).
14 STORAGE
 Thoroughly clean the whole machine and its accessories.
 Store it out of the reach of children, in a stable and secure position, in a cool and dry
place, avoid too high and too low temperatures.
 Protect it from exposure to direct sunlight. Keep it in the dark, if possible.

Don’t keep it in plastic bags to avoid humidity build-up.
