POWX200
EN
Copyright © 2011 VARO NV P a g e | 9 www.varo.com
Avoid using wet wood.
Regularly remove and clean away wood chips using caution.
Avoid using pieces that are too small.
Warning! Any blade part not in use must be protected!
Place the piece to be worked on the in feed table and progressively advance the piece to be
worked.
Warning! Advancing the piece too quickly generates burrs.
10 CLEANING AND MAINTENANCE
Attention ! Before performing any work on the equipment, pull the power
plug.
10.1 Cleaning
Keep the ventilation slots of the machine clean to prevent overheating of the engine.
Regularly clean the machine housing with a soft cloth, preferably after each use.
Keep the ventilation slots free from dust and dirt.
If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These
solvents may damage the plastic parts.
10.2 Lubrication
The machine requires no additional lubrication.
After about 10 hrs. of use we recommend checking or maintaining the following points:
Movement of the in feed and out feed rollers, cleaning if necessary.
Movement of the pulley.
Check the feed belts
Check the tightness of the nuts, gears, chains, table adjustment of the planer
Check the carbon brushes
10.3 Replacing Coal Brushes
Remove and check the carbon brushes reguarly. Replace them when they have become
shorter then 5mm. Keep the carbon brushes clean and free to slip in the holders. Both carbon
brushes must be replaced at the same time. Only use original carbon brushes.
11 TECHNICAL DATA
Voltage / frequency 230V / 50Hz
Power input 1800W
No load speed 9000rpm
Cuts / min : 18,000
Min. Planing length: 140 mm
max planing width : 330mm
planing height / depth : 5 > 150 mm
planing dept per go : 0,1 - 3 mm Max
feeding speed : 4 & 6m/min
digital display accuracy : 0.1mm
Safety class I
net weight : 40kg
