9.9.2 Securing the tool head (Fig. 42)
Secure the tool head by tightening the lever in the direction of arrow shown in the figure.
9.9.3 Releasing the lower limit stopper (Fig. 43)
Make sure that the end of the lower limit stopper is at the A position in the figure. Turn the end
of the lower limit stopper counterclockwise to the A position when it is positioned at the B
position.
9.9.4 Repositioning the riving knife (Fig. 44)
The position (Fig. 44-A) should be changed as follows.
(1) Loosen the clamping nut. (Fig. 44-B)
(2) Pull and pivot the riving knife to the position at the angle of 90° in the direction of arrow.
(Fig. 44-C) And push in it slightly so that it become still in this position.
(3) Raise the lower blade guard fully using its lug by hand while pushing the lever nearby the
handle to the left, and release the lever nearby the handle. (Fig. 44-D)
(4) Push the riving knife in the direction of arrow (see Fig. 44-E) so that it is aligned with the
saw blade.
(5) After pushing the riving knife in the direction of arrow shown in the figure, release the lower
blade guard
(6) After aligning the riving knife, tighten the clamping nut securely (see Fig. 44-F).
9.9.5 Removing the lower blade guard (Fig. 45)
Remove the lower blade guardfrom the table by loosening the clamping screw.
9.9.6 Locking the tool head at fully lowered position (Fig. 46)
After setting up the riving knife in position for table saw mode, pull the stopper in the direction
of arrow A and turn it to the angle of 90° in the direction of arrow B with the stopper pulled.
Then lower the handle to lock the tool head.
CAUTION:
 When the tool head cannot be locked in the fully lowered position, turn the depth adjusting
knob by several turns clockwise. (Fig. 47)
 Before turning over the tool, always make sure that the stopper pin has securely locked the
tool head in the lowest position.
9.9.7 Turning over the tool (Fig. 48)
WARNING:
 Make sure that the tool is switched off and unplugged before turning over.
 When pushing down the lever, be sure to place your hand/finger away from the lever-table
fitting area. Hold the middle edge of table with one hand, push the lever down with the other
hand while holding the table edge firmly and pivot the table carefully to turn it over. Keep
holding it until it locks.
9.9.8 Installing the top blade guard (Fig. 49)
Push the push button of the top blade guard to its side surface, place it on the notch of the
riving knife with the button depressed and release the button. After releasing the push button,
make sure that the top blade guard is secured by trying to pull it out.
CAUTION:
 After installing the top blade guard, make sure that it works smoothly.
