POWX0650 EN
Copyright © 2014 VARO P a g e | 7 www.varo.com
7.3 Turning the machine on/off
 Press the safety switch (5) and push the ON/OFF switch trigger (4), the machine is on.
 Release the trigger, the machine is off.
CAUTION! Always run the machine at no load for at least 30 seconds before
starting work. Damaged, out-or-round or vibrating diamond cutting discs
may not be used.
 Soft start: The machine is fitted with a soft start mechanism.
 Overload protection: The machine has an overload protection device and automatically
switches off when overloaded. Release the trigger and remove the machine from the
work-piece, restart and run the machine at no-load for approximately one minute to cool
the machine down.
7.4 Adjusting the case width (Fig. 4, Fig. 5, Fig. 6, Fig. 7)
 The machine is supplied with four spacer rings (15) which are each approximately 10 mm
thick. The chase width can be adjusted by varying the amount of spacer rings fitted
between the diamond cutting discs. The chase width can be calculated by taking into
account the thickness of the spacer rings and the width of the diamond cutting discs. The
maximum chase width is approximately 44mm.
7.5 Dust extraction
 The machine may only be operated when connected to a suitable vacuum device, the
vacuum device must be approved for stone dust. A dust extraction adapter (3) is supplied,
ensure that the hose is securely attached to the adapter. Stop work immediately when the
vacuum device breaks down. Switch the machine off and restore the vacuum device. The
vacuum device must be suitable for the type of material you work with. Use a special
vacuum device when working with toxic materials or where toxic dust is produced. Use of
a household vacuum cleaner may damage your health.
 For best results use a wet and dry vacuum device fitted with an appropriate filter. If in
doubt seek expert advice.
8 OPERATION
Mark the line of cut before starting work, hold the machine tightly with both
hands. (Fig. 8)
1. Set the chase depth. Place the front roller wheel of this machine firmly against the wall.
Switch the machine on and gently lower the machine towards the wall until the rotating
diamond cutting discs plunge into the wall, hold the machine tightly with both hands.
2. Carry out the cut steadily, evenly and with moderate pressure appropriate to the material
being cut. Ensure you work in the correct direction! Always work against the direction of
rotation as shown on the machine
’s protective guard to avoid the risk of the machine
being forced uncontrolled of the cut.
3. After completing the cut, retract the machine slightly, switch off and remove from the cut.
 Allow the diamond cutting discs to stop before putting the machine down. Do not attempt
to brake the diamond cutting discs by applying lateral pressure.
 Remove the remaining masonry in the chase using the masonry breaking tool provided.
 It is not possible to make curved cuts with the machine as the diamond cutting discs may
seize in the cut.
 Paving slabs or similar must be placed on a solid surface or be otherwise securely
supported before starting the cut to avoid breakage.
