POWAIR0310 EN
Copyright © 2013 VARO P a g e | 6 www.varo.com
Fig. 1
1.
Tool
2. Quick connector
3. Quick coupler
4. Air hose
5. Quick connector
6. Quick coupler
7. Lubricator
8. Regulator (0-8.5 bar)
9. Filter
10. Cut-off valve
11. Air compressor
9 MAINTENANCE
Disconnect the tool from the compressor before adjusting, clearing jams,
servicing & maintenance, relocating and during non operation.
 Regular lubrication. If you use your tool without using the in-liner automatic oilier,
place 2 or 6 drops of pneumatic tool oil into the air inlet before each work day or
after 2 hours of continuous use depending in the characteristic of work piece or type
of fasteners.
 Air-operated tools must be inspected periodically, and worn or broken parts must be
replaced to keep the tool operating safely and efficiently. Check and change all worn
or damaged O-ring, Seals, etc. Tight all the screws and caps to prevent personal
injury.

Make regular inspection for free movement of trigger, spring and safety mechanism
to assure safe system is complete and functional: no loose and missing parts, no
building up of dirt and no jammed fasteners.

Keep magazine and nose of tool clean and free of any dirt lint or abrasive particles.

When temperatures are below freezing, tools should be kept warm by any
convenient, safe method.
10 TECHNICAL DATA
Model POWAIR0310
Activation mode Single sequential action
Max. allowable pressure 120 PSI (8.3 bar)
Air inlet size ¼”
Avg. air consumption 78.68 l/min (2.78 cfm)
Recommended lubricant White mineral oil
Nail capacity 100 pcs
11 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
88 dB(A)
Acoustic power level LwA 101 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
