- 5 -
1.3 Specifications
Pickup Device 1/2.7" 2 megapixel CMOS sensor
Image area for FOV 1080 mode: 6.61 mm diagonal; 5.76 mm H x 3.24 mm V
Image area for FOV 720 mode: 4.41 mm diagonal; 3.84 mm H x 2.16 mm V
Sensitivity 0.5lux/F=1.4
S/N Ratio 45dB
Video Format Main Output HDcctv
Resolution Main Output 1920x1080 or 1280x720 field select
Video Mode Main Output Field select 1080i60, 1080p30 or 720p60 for 60Hz systems
1080i50, 1080p25 or 720p50 for 50Hz systems
Main Output Connector BNC-F
Video Format Test Output NTSC/PAL selectable 1V p-p
Test Output Connector Pin header; adapter cable to BNC-F supplied
Electronic Shutter Auto, 1/60(1/50)~1/8000
Lens Type Megapixel Varifocal lens, Auto Iris, f=3.3~12mm, F=1.4
True Day/Night Control Yes (Auto IR cut filter removal)
Back Light Compensation On/Off selectable
Auto Gain Control High/Middle/Low/Off selectable
Auto White Balance AWB/One Push WB/Manual WB/Indoor/Outdoor selectable
Gamma Correction PC/TV selectable
OSD Menu Yes (controlled from 5-axis joystick control)
Mirror H_MIR/V_MIR/Rotate
Power Source 12VDC/24VAC
Power Consumption 24VAC: 5.5W max. (230mA nominal)
12VDC: 3.3W max. (275mA nominal)
Dimensions ( ϕ x H) 123 mm (O.D.) x 107.8 mm (H)/ 4.8” (O.D.) x 4.2 “(H)
Weight 740kg /1.6 lbs
Operating Temperature -10°C~50°C ; 14°F~122°F
Weatherproof IP66 rated
Vandal Resistant Yes
Certifications FCC/CE
