MIDI Data Format
A-34
J DSP Reverb Send Level
F0 44 7E 02 00 10 40 20 05 0D 00 00 2F 00 00 00 00 06 00 04 00
00 07 vl 00 F7
vl = 0 to 7F :
Send
This message is sent when a function switch operation or
other DSP reverb send level setting operation is performed.
Receive
Receipt of this message changes the DSP reverb send level
setting.
J Keyboard/Song Volume
F0 44 7E 02 00 10 40 20 05 0D 00 00 2F 00 00 00 00 0D 00 04
00 00 07 vl 00 F7
vl = 0 to 7F :
Send
This message is sent when a keyboard/song volume knob
operation or other keyboard/song volume setting
operation is performed.
Receive
Receipt of this message changes the keyboard/song volume
setting.
J Part DSP On/Off
F0 44 7E 02 00 10 40 20 05 0D 00 00 2F 00 00 00 00 10 00 04 00
pp 07 vl 00 F7
pp = Part : 0 to 1F (Group A : 00H to 0FH , Group B : 10H to
1FH)
vl = 0 : Off
vl = 1 : On
Send
This message is sent when a mixer or other part DSP on/off
operation is performed.
Receive
Receipt of this message changes the part DSP on/off setting.
J Master Tune
F0 44 7E 02 00 10 40 20 01 00 00 00 2F 00 00 00 00 10 00 08 00
00 00 0F vl vh 00 F7
Range
0018H : –100.0[cent] : Lower Limit : Reference Setting
Values vl = 18H, vh = 00H : A
4 = 415.3Hz
0400H : 0.0[cent] : Center Value : Reference Setting Values
vl = 00H, vh = 08H : A
4 = 440Hz
07E8H : +100.0[cent] : Upper Limit : Reference Setting
Values vl = 68H, vh = 0FH : A
4 = 466.2Hz
Send
This message is sent when a function switch operation or
other master tune setting operation is performed.
Receive
Receipt of this message changes the master tune setting.
J Master Key Shift (Transpose)
F0 44 7E 02 00 10 40 20 01 00 00 00 2F 00 00 00 00 11 00 08 00
00 00 07 vl 00 F7
Range
28H : –24 [semitones] : Lower limit
40H : 0 [semitones] : Center value
58H : +24 [semitones] : Upper limit
Send
This message is sent when a transpose operation or other
master key shift setting operation is performed. The value
is offset by –1 when baroque pitch is turned on.
Receive
Receipt of this message sets the master key shift.
* A transpose switch operation on this device sends a value
in the range of 34H to 4CH.
J Master Pan
F0 44 7E 02 00 10 40 20 01 00 00 00 2F 00 00 00 00 13 00 08 00
00 00 07 vl 00 F7
Range
00H : –64 (left)
40H : 0 (center)
7FH : +64 (right)
Send
This message is sent when a function switch operation or
other master pan setting operation is performed.
Receive
Receipt of this message sets the master pan.
* Note that 00H = 01H.
