MIDI Data Format
A-26
J NRPN (Non-Registered Parameter Numbers)
With the instrument, NRPN are defined as tone editing
parameters. The MSB and LSB of an NRPN specify the
parameter being controlled, while the specified parameter’s
value is set in accordance with the subsequent data entry.
The following table shows the relationship between
parameters and NRPN as defined by the instrument.
See “Vibrato Rate” through “Filter/AMP Envelope Release
Time” for the data entry MSB value range and other details.
Format
n..........Voice Channel Number = 0H to FH (Ch1 to Ch16)
pm ......MSB of NRPN
pl ........LSB of NRPN
Recognition
Š NRPN messages not defined by the instrument can also
be received, but subsequent data entry values after
undefined NRPN messages are ignored.
Š After the NRPN MSB and LSB are received and the
applicable control parameters settings are made, the
value is set by receipt of the MSB of the subsequent data
entry. The data entry LSB is ignored.
Send
An NRPN and data entry are sent whenever an operation
that changes the parameter assigned to the NRPN (such as
Vibrato Rate).
Vibrato Rate
NRPN MSB = 01H
NRPN LSB = 08H
Data Entry MSB = mmH
mm .....Vibrato Rate = 00H to 40H to 7FH (–64 to 0 to +63)
Recognition
When the instrument receives this message, the preset
Vibrato Rate value for the tone is changed to the Vibrato
Rate value that corresponds to the data entry MSB of the
received message. There is no change when the value of the
data entry MSB is 40H(0).
Send
This message cannot be sent.
Vibrato Depth
NRPN MSB = 01H
NRPN LSB = 09H
Data Entry MSB = mmH
mm .....Vibrato Depth = 00H to 40H to 7FH (–64 to 0 to +63)
Recognition
When the instrument receives this message, the preset
Vibrato Depth value for the tone is changed to the value
that corresponds to the data entry MSB of the received
message. There is no change when the value of the data
entry MSB is 40H(0).
Send
This message cannot be sent.
Vibrato Delay
NRPN MSB = 01H
NRPN LSB = 0AH
Data Entry MSB = mmH
mm .....Vibrato Delay = 00H to 40H to 7FH (–64 to 0 to +63)
Recognition
When the instrument receives this message, the preset
Vibrato Delay value for the tone is changed to the value
that corresponds to the data entry MSB of the received
message. There is no change when the value of the data
entry MSB is 40H(0).
Send
This message cannot be sent.
NRPN
MSB
NRPN
LSB
Parameter
01H 08H Vibrato Rate
01H 09H Vibrato Depth
01H 0AH Vibrato Delay
01H 20H Filter Cut Off Frequency
01H 21H Filter Resonance
01H 63H Filter/AMP Envelope Attack
Time
01H 64H Filter/AMP Envelope Decay Time
01H 66H Filter/AMP Envelope Release
Time
Byte 1 Byte 2 Byte 3
BnH 63H pmH (MSB)
BnH 62H plH (LSB)
