E-37

ACCOMP MIDI OUT (Default: Off)

on:

Auto Accompaniment is played by the keyboard and the corre-
sponding MIDI message is output from the MIDI OUT terminal.

oFF:

Auto Accompaniment MIDI messages are not output from the
MIDI OUT terminal.

1.

Press the TRANSPOSE/TUNE/MIDI button until the
ACCOMP MIDI OUT screen appears.

Example: When ACCOMP MIDI OUT is off

2.

Use the [+] and [–] or [0] and [1] buttons to turn the
setting on and off.

Example: To turn ACCOMP MIDI OUT on

TOUCH CURVE (Default: 0)

0:

Normal touch curve

1:

Louder than normal tone, even when little pressure is used to press
keyboard keys. When touch response is turned off, sound is pro-
duced at a louder volume than normal.

1.

Press the TRANSPOSE/TUNE/MIDI button until the
TOUCH CURVE SELECT screen appears.

2.

Use the [+] and [–] or [0] and [1] buttons to change
the setting.

Example: To select touch curve 1

MIDI IN CHORD JUDGE (Default: Off)

on:

When a chord specification method is selected by the MODE
switch, chords are specified by the keyboard channel note data
input from the MIDI IN terminal.

oFF:

MIDI IN CHORD JUDGE is turned off.

1.

Press the TRANSPOSE/TUNE/MIDI button until the
MIDI IN CHORD JUDGE screen appears.

2.

Use the [+] and [–] or [0] and [1] buttons to turn the
setting on and off.

Example: To turn MIDI IN CHORD JUDGE on

NOTE

MIDI IN CHORD JUDGE automatically turns off whenever you change the
navigate channel to any channel besides 01.

LOCAL CONTROL (Default: On)

This setting determines whether or not the keyboard and sound source
of this keyboard are connected internally. When recording to a com-
puter or other external device connected to this keyboard’s MIDI IN/
OUT terminal, it helps if you turn LOCAL CONTROL off.

on:

Anything played on the keyboard is sounded by the internal
sound source and simultaneously output as a MIDI message from
the MIDI OUT terminal.

oFF:

Anything played on the keyboard is output as a MIDI message
from the MIDI OUT terminal, without being sounded by the in-
ternal sound source. Turn LOCAL CONTROL off whenever you
are using the MIDI THRU function of a computer or other exter-
nal device. Also note that the no sound is produced by the key-
board if LOCAL CONTROL is turned off and no external device
is connected.

1.

Press the TRANSPOSE/TUNE/MIDI button until the
LOCAL CONTROL screen appears.

Example: When LOCAL CONTROL is on

2.

Use the [+] and [–] or [0] and [1] buttons to turn the
setting on and off.

Example: To turn LOCAL CONTROL off

LOCAL CONTROL On
Notes played on the keyboard are
sounded by the internal sound
source and output as MIDI mes-
sages from the MIDI OUT termi-
nal.

LOCAL CONTROL Off
Notes played on the keyboard are
output as MIDI messages from
the MIDI OUT terminal, but not
sounded directly by the internal
sound source. The MIDI THRU
terminal of the connected device
can be used to return the MIDI
message and sound it on this key-
board’s sound source.

474A-E-039A
