Specifications – Elmo L-1EX User Manual

Page 66

TIO

English

General

Item

Specifications

Power source

12VDC (AC adapter AC100 - 240V)

Power consumption

15W (AC adapter included)

Outside dimensions

W350 x D370.5 x H411.5mm (W13.8 x D14.6 x H16.2 in)

(When setup)
W195 x D254.5 x H444.5mm (W7.7 x D10.0 x H17.5 in)

(When folded)

Weight

Approx. 2.9kg (6.4 lbs) (Main body only)

Input selection

Main/External

Output terminal

RGB output Mini Dsub 15P connector, female x 1

Composite video output RCA pin jack/75

Ω unbalanced x 1

(NTSC/PAL)

Input terminal

Input terminal RGB input Mini Dsub 15P connector female x 1

Recorder terminal

Dedicated connector

Ext. control terminal

USB (2.0 compliant) Type B receptacle x 1

Memory Interface

SD card slot x 1

∗Use pin plug for RCA pin in accordance with EIAJ RC-6703.

Main Camera

Item

Specifications

Lens

f = 3.85mm – 20.02mm (5.2-time zoom) F2.8 – 3.2

Frame rate

Max. 30 frames/sec.

Shooting area

SXGA : Max 417x331mm Min. 92x74mm

WXGA : Max 417x246mm Min. 92x56mm

XGA : Max 417x309mm Min. 92x69mm

Limit of focus

adjustment

50mm - (2.0 in x ) from lens top

Optical zoom

5.2X

Digital zoom

Focus

Auto/Manual

Image pick-up element

1/3” CMOS

Total pixels

Horizontal 1384, Vertical 1076 ... Approx. 1,490,000 pixels

Effective pixels

Horizontal 1329, Vertical 1049

Synchronized signal

Internal

Resolution

Analog RGB Horizontal 800TV lines or more Vertical 800TV lines or

Video output Horizontal 500TV lines or more


