12 GB/MT
Kitchen Mixer Tap
Proper use
Suitable for use with all pressure-resistant hot water
systems such as central heating, continuous-flow
water heater, pressure boiler etc. It is not suitable
for low pressure water heaters such as wood-burn-
ing or coal-burning domestic hot water geysers, oil
or gas-fired hot water geysers, or open electrically
heated cylinders. If in doubt, please consult a
plumber or heating specialist. Any use other than
that described here, or any modification to the
product, is not permitted and may lead to damage
to persons or property. There is also the risk of
injury and loss of life. The product is for private use
only and is not intended for medical or commercial
use. The manufacturer does not accept any liability
for any damage caused by improper use.
Description of parts
and features
1 1 Fastening screw (swivel arm)
2 1 Threaded ring
3 1 Sealing ring
4 1 Seal
5 1 Metal seal
6 1 Threaded bushing
7 1 Threaded ring
8 2 Locking screws
9 2 Flexible hoses
10 1 Changeover switch (spray head)
11 1 Sealing ring (spray head)
12 1 Mixing nozzle
13 1 Adjusting lever
14 1 Locking screw
15 1 Hot / cold label
16 1 Cartridge cover ring
17 1 Cartridge securing ring
18 1 Adjusting ring
19 1 Cartridge
20 1 Hexagonal key
Technical data
Connections: G⅜” (approx. 17 mm)
Nut (water supply): approx. 19 mm
Hot water temperature: max.: 85 °C
Operating pressure:
min.: 0.5 bar
max.: 5 bar
Safety advice
DANGER OF
LOSS OF LIFE AND ACCIDENT
TO INFANTS AND CHILDREN!
Never leave children unsupervised with the
packaging materials. Danger of suffocation.
Keep out of the reach of children. It is not a toy.
BEWARE OF ELECTRIC SHOCK!
Leaks can put your life at risk from
electric shocks. Carefully check that
all connections are watertight. Also ensure that
all wires of electric appliances are correct and
have been securely installed.
CAUTION! RISK OF INJURY! Ensure all
parts are undamaged and correctly assembled.
Incorrect assembly poses the risk of injury.
Please observe that washers and seals are
wear-and-tear parts that must be replaced from
time to time. Damaged parts may have an
effect on the safety and function.
ATTENTION! RISK OF MATERIAL DAM-
AGE! Installation may only be carried out by
experts. Leakage or escape of water can cause
significant damage to buildings and household
contents. All connections must therefore be
checked carefully to ensure that they are tight.
Ensure that all seals are correctly seated to
avoid escape of water due to leakage.
Turn the drain pipe in the desired position but
make sure that it is facing the sink. Otherwise
water leakage can lead to considerable dam-
age to buildings.
CAUTION! RISK OF SCALDING! When
setting the hot water please ensure that the
temperature of the water is not too high.
