FR524, FR604, FR724 DECK GROUP
4
Item
Part No.
Description
Qty.
1 1-303334 Washer, Spring Disc 5/16 ...................... 1
2 323-20 Screw, HH 3/8-16 x 3-1/4 ....................... 2
3 1-322110 Wld, Belt Guide...................................... 1
4 1-323385 Knob, 3 Prong........................................ 4
5 1-373034 Washer .................................................. 2
6 98-5975 Washer, Spring Disc 3/8 ........................ 3
7 32120-10 Ring, Retaining ...................................... 2
8 1-602913 -01 Wld, Baffle Discharge ............................ 1
9 1-603805 Sheave, Idler.......................................... 1
10 109-2796 Sheave, Flat Idler................................... 2
11 1-633366 Belt, Blade Drive (52”)............................ 1
1-633127 Belt, Blade Drive (60”)............................ 1
1-643052 Belt, Blade Drive (72”)............................ 1
12 109-2985 Strip, Seal, 2” ......................................... 2
13 103-3900 Spacer, Strut.......................................... 4
14 1-633456 Bushing, Idler......................................... 2
15 103-2916 Guard, Top............................................. 1
16 103-3330 Spring, Extension................................... 1
17 103-3504 Bearing, Spherical.................................. 2
18 98-5961 Screw, HH 3/8-16 x 4 Gr8 ...................... 1
19 103-3505 Seal, Double Lip..................................... 1
20 103-3506 Seal, Single Lip...................................... 1
21 103-5677 Spacer ................................................... 1
22 103-5693 Asm, Deck Idler ..................................... 1
23 63-8410 Washer .................................................. 4
24 105-7699 Strip-Seal, 3".......................................... 2
25 106-7159 O-Ring ................................................... 2
27 302-40 Zerk, 90° 1/4-28 ..................................... 1
28 322-2 Screw, HH 5/16-18 x 5/8 ........................ 5
29 322-6 Screw, HH 5/16-18 x 1 1/4 ..................... 1
30 323-12 Screw, HH 3/8-16 x 2 1/2 ....................... 3
Item
Part No.
Description
Qty.
31 3234-11 Screw, HH FLG 3/8-16 x 1 ..................... 1
32 3256-24 Washer, 3/8 SAE ................................... 3
33 3256-3 Washer, 5/16 Std................................... 2
34 109-2392 Shield, Belt LH (60”) .............................. 1
109-5405 Shield, Belt LH (72”) .............................. 1
35 109-2391 Shield, Belt RH (60”).............................. 1
109-5404 Shield, Belt RH (72”).............................. 1
36 32128-20 Nut, Whizlock 5/16-18 ........................... 6
37 3296-39 Nut, Nyloc 3/8-16 ................................... 3
38 109-2393 Shield, Belt (52””)................................... 2
39 109-4383 Asm, Deck W/Decals (52”) .................... 1
109-5393 Asm, Deck W/Decals (60”) .................... 1
109-5406 Asm, Deck W/ Decals (72”) ................... 1
40 3290-357 Nut, Whizlock 3/8-16 ............................. 2
41 3256-4 Washer, 3/8 Std..................................... 2
42 1-633922 Decal, Anti-Scalp ................................... 1
43 109-2354 Decal, Crushing Hazard......................... 2
44 109-2359 Decal, Deck Warning............................. 1
46 109-3148 Decal, Bolt Torque ................................. 1
47 1-643222 Decal, Belt Routing ................................ 1
48 109-2376 Decal, Crushing Hazard......................... 1
49 103-8425 Decal, Driveline ..................................... 1
50 103-1145 Decal, Ultracut (52”)............................... 1
103-1146 Decal, Ultracut (60”)............................... 1
103-1147 Decal, Ultracut (72”)............................... 1
51 1-403005 Danger, Decal........................................ 2
52 1-303508 Decal, Discharge Warning ..................... 1
53 98-5954 Decal-Danger ........................................ 3
54X 109-4382 Asm, Deck Complete (52”) .................... 1
109-4380 Asm, Deck Complete (60”) .................... 1
109-5419 Asm, Deck Complete (72”) .................... 1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Kit also includes items #2. & #37
X Complete deck assembly includes all items from pages 4 & 6 except drive shaft assembly, drive shaft assembly hardware, deck
chain, and deck chain hardware on page 5.
