Excalibur ® P90 Zero Clearance Direct Vent Gas Fireplace 47
PARTS LIST
MAIN ASSEMBLY
Part #
Description Part # Description Part # Description
1) 430-129 Receptacle Box Mount
2) * Thermodisc Bracket
7) 910-428 Duplex Receptacle
8) 910-429 Box - Receptacle
9) 910-430 Cover - Receptacle
10) 904-687 Clamp Connector
15) * Heat Shield - Base
20) 790-021 Front Filler - Left Corner
21) 790-022 Front Filler - Right Corner
22) 790-012 Baffl e
23) 780-011 Standoff
- Top
24) 780-013 Standoff - Side
25) 780-091 Standoff
- Rear
27) * Outer Flue Collar
28) * Inner Flue Collar Assy
30) * Gasket for Flue Collar
31) * Flue Mounting Bracket
32) 902-600 Brick Panel - Base
790-901 Brick Panel Set -
Standard Brown
790-902 Brick Panel Set -
Standard Red
790-903 Brick Panel Set -
Herringbone Brown
33) * Brick Panel - Back
34) * Brick Panel - Left
35) * Brick Panel - Right
36) 904-716 #10 x 5/8" Butt Spacer
511-031
Brick Panel Clip
432-967 Burner ON/OFF Switch Assy
38) 910-241 Switch-Burner
ON/OFF(3-way)
910-899 Wire Harness - Valve
to Burner
42) 910-331/P Fan Motor (120 Volts)
432-966 Fan Switch Assembly-120 V
(Optional)
43) * Power Cord (120 Volts)
910-845 Wire Harness - Plug In Fan
46) 910-330 Fan Speed Control Switch
47) 904-586 Knob - Speed Control
48) 910-199 Wire
Holder Clip
49) 910-142 Thermodisc-Fan Auto On/Off
910-845 Wire Harness - Plug in Fan
904-713 U-clip at Louver
50) 510-994 Rigid Pipe Adaptor (Optional)
51) 790-011 Relief Frame Gasket
59) 790-009 Relief Door Mounting Plate
60) W260260 Top
Relief Frame Gasket
61) 942-117 Top Relief Plate Frame
62) W260280 Top Relief Plate Gasket
63) 290-021 Air
Baffl e Plate
64) 790-093 Gasket - Exchanger Relief
946-556 Heat Wave Duct Kit (Optional)
89) 946-004 Junction Box
90) 946-000 Round Duct Adaptor
91) 946-002 Round to Oval Adaptor
92) 946-001 Oval
Duct Adaptor
93) 946-007 Angle Bracket
94) 946-517/P Fan Assy - HeatWave Option
95) 946-006 Grill Plate - White
96) 946-005 Wall Adaptor Plate - White
97) 910-417 Knob
- White
98) 910-366 Switch Cover Plate - White
99) 910-412 Fan Speed Controller
100) 910-367 Box-Plastic Switch
Receptacle
102) 946-010 Flexible Air Duct
946-038 Insulation 6" dia. x 24"
946-570
Heat Release Duct Kit
(Optional)
108) 910-165 Fan (120 V)
109) 946-000 Flexible Air Release Duct
918-525 Manual
791-969 Conversion Kit - NG to LP
*Not available as a replacement part.
