80 GB/MT
Q
Weather station
j Mark the position of the hole (ø approx. 7 mm)
on the wall.
j Drill the hole with an electric drill.
j Insert the dowel 23 into the drilled hole.
j Using a crosshead screwdriver, screw the
screw
24 into the dowel 23 .
j Hang the weather station by placing the hanger
20 on the screw 24 .
Q
External sensor
j Mark the position of the hole (ø approx. 5 mm)
on the wall.
j Drill the hole with an electric drill.
j Insert the dowel 28 into the drilled hole.
j Using a crosshead screwdriver, screw the
screw
29 into the dowel 28 .
j Hang the external sensor by placing the
hanger
26 on the screw 29 .
note: Choose a sheltered position for the external
sensor, not directly near the weather station (e.g.
separated by a wall). Ensure that the external sensor
does not come into contact with water or direct
sunlight. Electronic devices may adversely affect
the wireless signal reception.
Q
Setting up the weather station
j Place the stand 22 on the underside of the
weather station.
